You can rest assured to buy the Gangxin Copper tripod fittings produced by our factory. This product is made by traditional bending technology, with uniform wall thickness, strong pressure resistance, in line with ROHS and REACH environmental protection testing, beautiful appearance, convenient size installation and advanced technology;
Copper tripod fittings is a kind of pipe assembly for connecting copper pipe, has a wide range of applications. copper M-type tee pipe fitting, as a kind of copper pipe fitting, for its excellent thermal conductivity characteristics, is widely used in the field of air conditioning and refrigeration. this fitting design allows the gas and liquid, for refrigeration tube components and plumbing pipe component, are widely used in residential or commercial central air conditioning, automobile air conditioning, refrigeration, building plumbing, medical oxygen copper pipes, gas pipeline, etc. Copper tripod fittings is mainly connected by expanding pipe connection, this connection ensures a close connection between the pipe fittings and copper pipe, has good sealing and pressure resistance.
|
Model |
Pipe Diameter |
A |
B |
C |
R |
D(Φ) |
H |
T |
Figure |
|
GX-M-01 |
5 |
17.5 |
9.5 |
6.0 |
5 |
5.00 |
17.0 |
0.41 |
Figure 1 |
|
GX-M-02 |
5 |
19.05 |
8.75 |
6.0 |
5 |
5.00 |
17.0 |
0.41 |
Figure 1 |
|
GX-M-03 |
6 |
13.89 |
9.4 |
6.0 |
5 |
5.00 |
18.2 |
0.41 |
Figure 1 |
|
GX-M-04 |
6 |
19.5 |
11.6 |
5.0 |
5 |
5.00 |
21.0 |
0.41 |
Figure 2 |
|
GX-M-05 |
6.35 |
17.6 |
15.9 |
6.0 |
6 |
6.35 |
20.0 |
0.5 |
Figure 3 |
|
GX-M-06 |
6.35 |
17.6 |
15.9 |
6.0 |
6 |
6.35 |
20.0 |
0.5 |
Figure 4 |
|
GX-M-07 |
7 |
17.6 |
14 |
6.0 |
9 |
6.35 |
20.0 |
0.5 |
Figure1 |
|
GX-M-08 |
7 |
21 |
12.7 |
6.0 |
9 |
7.00 |
19.0 |
0.5 |
Figure 1 |
|
GX-M-09 |
7 |
21 |
18.2 |
6.0 |
9 |
7.00 |
21.0 |
0.5 |
Figure 1 |
|
GX-M-10 |
7 |
25.4 |
10.5 |
6.0 |
9 |
7.00 |
19.0 |
0.55 |
Figure 1 |
|
GX-M-11 |
7 |
22 |
19.05 |
8.0 |
9 |
7.00 |
22.0 |
0.55 |
Figure 1 |
|
GX-M-12 |
7.2 |
25 |
12.5 |
8.0 |
10.5 |
7.20 |
22.0 |
0.55 |
Figure 1 |
|
GX-M-13 |
7.94 |
25.4 |
19.05 |
8.0 |
10.5 |
7.94 |
22.0 |
0.6 |
Figure 2 |
|
GX-M-14 |
7.94 |
22 |
19.05 |
8.0 |
10.5 |
7.94 |
22.0 |
0.6 |
Figure 2 |
|
GX-M-15 |
9.52 |
25.4 |
15.88 |
8.0 |
10.5 |
9.52 |
24.0 |
0.6 |
Figure 1 |
|
GX-M-16 |
9.52 |
25 |
21.65 |
8.0 |
10.5 |
9.52 |
24.0 |
0.6 |
Figure 1 |
|
GX-M-17 |
9.52 |
25.4 |
22.9 |
8.0 |
10.5 |
9.52 |
23.0 |
0.6 |
Figure 3 |
|
GX-M-18 |
12.70 |
31.75 |
27.5 |
8.0 |
10.5 |
12.70 |
30.0 |
0.7 |
Figure 1 |
|
GX-M-19 |
12.70 |
30 |
26 |
10.0 |
12.5 |
12.70 |
30.0 |
0.7 |
Figure 1 |
