What Is a Branch Pipe
2025-08-14Introduction to Branch Pipes
Branch pipes are essential components in piping systems that allow for the division or redirection of fluid flow. At Gangxin Hardware, we specialize in manufacturing high-quality branch pipes for various industrial applications. This guide will explore branch pipe types, specifications, installation methods, and maintenance practices to help you select the right component for your system.
Types of Branch Pipes and Their Applications
Common Branch Pipe Varieties
| Type | Description | Typical Applications |
|---|---|---|
| Tee Branch | 90° connection with equal diameters | Water supply, HVAC |
| Lateral Branch | 45° connection | Petroleum, chemical |
| Reducing Branch | Different diameter connections | Industrial processing |
| Reinforced Branch | Extra wall thickness | High-pressure systems |
Material Selection Guide
-
Carbon Steel: General industrial use (ASTM A234)
-
Stainless Steel: Corrosive environments (ASTM A403)
-
Alloy Steel: High-temperature services (ASTM A234 WP)
-
PVC/CPVC: Chemical processing
Technical Specifications of Gangxin Branch Pipes
Product Specifications Table
| Model | Material | Size Range | Pressure Rating | Temperature Range | Connection Type |
|---|---|---|---|---|---|
| GX-BP100 | Carbon Steel | 1/2"-24" | 150#-900# | -29°C to 425°C | Butt Weld |
| GX-BP200 | Stainless 316 | 1/2"-16" | 150#-2500# | -196°C to 800°C | Socket Weld |
| GX-BP300 | Alloy Steel | 1/2"-12" | 900#-4500# | -50°C to 1000°C | Threaded |
Key Features
✔ Precision CNC machining (±0.1mm tolerance)
✔ 100% radiographic testing (RT) for critical applications
✔ Beveled ends for perfect weld alignment
✔ Internal surface finish: Ra ≤ 3.2μm
✔ Hydrostatic tested at 1.5x working pressure
Installation and Maintenance Best Practices
Installation Guidelines
-
Alignment check: Verify pipe run dimensions before cutting
-
Welding preparation: Clean beveled ends thoroughly
-
Support requirements: Install within 1m of branch connection
-
Pressure testing: Conduct after installation
Maintenance Schedule
| Task | Frequency | Method |
|---|---|---|
| Visual Inspection | Monthly | Check for corrosion |
| Thickness Test | Annually | Ultrasonic measurement |
| Pressure Test | Biannually | Hydrostatic method |
| Internal Cleaning | Quarterly | Pigging or chemical flush |
Why Choose Gangxin Hardware Branch Pipes?
✔ 15+ years of specialized manufacturing experience
✔ ISO 9001 certified quality system
✔ Complete material traceability with MTCs
✔ Custom fabrication services available
✔ Competitive lead times (15-30 days)
Contact Our Piping Experts Today:
📧 Email: tiandefa@gxteepipe.com
As Gangxin's technical director with 20 years in piping systems, I guarantee our branch pipes deliver reliable performance in the most demanding applications. Let us help you solve your piping challenges!
